Standard Equipment

• 35 Ton hydraulic wrecker
• 90" sliding boom
• Locks on sliding system
• Dual 30,000lbs hydraulic planetary winches
• 5/8" x 200' steel cable on each drum
• Air clutch release on winches
• Air cable tensioners
• Direct mounted tandem hydraulic pump
• Dual 6" bore x 40 5/8" cylinder for power boom elevation
• Lock & safety valve on elevation cylinder
• Two stage power boom extension
• Directional boom sheave
• Nylon slide on boom
• Dual independent hydraulic rear stiff legs
• Removable spades for stiff legs
• Lubrication fittings on all moving parts
• Dual control

• Lights in lever controls
• 2 Pressure gauges
• Heavy duty body 96" wide
• Two toolboxes (36 Cubic Ft.)
• 168" C.A. (From cab to center of rearmost axle)
• Hi-tensile steel used for structural parts
• Sandblast + Epoxy primer paint
• Undercoating underneath the body
• Monocoque body
• Rear mounted recovery anchors
• Safety chains (2 - 3/8" x 15' grade 7)
• Federal standard #108 light group
• Door checks & hold backs
• Air plug (truck must have trailer air system)
• Electric plug
• Mud flaps

• Tri-axle body for 52" or 54" spread (26" longer, 194" C.A., small tool boxes)
• Reinforcement plate under the cab
• Reinforcement plate under the cab & bunk
• "L" shape mounting plate 3/8"
• "L" shape mounting plate T1 steel 3/8"
• Third stage boom
• Heavy duty axle-lift + 4 sets of brackets + tie down chains
• Super heavy duty axle-lift + 4 sets of forks + tie down chains
• Tunnel toolbox 24" or 28" or 32" or 36" or 40" or 44" or 48" single door
• Tunnel toolbox 48" or 52" or 56" or 60" or 64" or 68" or 72" double door
• Battery box inside the tunnel toolbox
• Work lights in toolboxes
• Light pylon
• Aluminum cover inside the light pylon

• Winch covers
• Aluminum checker plate on top of tunnel toolbox
• Aluminum checker plate on rear steps
• 2 Work lights under the bumper
• Stainless on boom
• Stainless on mast
• Stainless on light pylon
• Stainless on bottom of body
• Stainless on winch covers
• Stainless on levers control
• Stainless on top of body's sides
• One-color paint (acrylic enamel)
• One-color paint (IMRON)
• Installation (includes PTO)
